WEG MPW25 - 16-20A Motor Protective Circuit Breaker

MPW25-3-U20 (10409820)

Order Code: 22615
Photo of WEG MPW25 - 16-20A Motor Protective Circuit Breaker
Obsolete Product
This item is now obsolete. Alternatives may be available - see linked products below.

Brand: WEG, Range: MPW Circuit Breaker

WEG Automation MPW25 Series 16 - 20A Motor Protective Circuit Breaker. Provides short-circuit (magnetic) and motor overload (thermal) protection for a standard AC Motor. DIN rail mounting (optional lugs for direct panel mounting also available).

Size: 45mm Wide x 85mm Deep x 95mm High
Weight: 0.36kg

Maximum Voltage: 690V 50/60Hz
Trip: 16 - 20A (adjustable)
Terminals: Screw Type, X2 M4 20mm Phillips
Temperature compensation
Trip Indicator
Start lever can be locked in the OFF position with a padlock if required.

Download the WEG MPW25 Drawing from the link below:-
