Condition: New with Warranty Brand: Inverter Drive Supermarket, Range: Encased Dynamic Brake Resistors
Dynamic Braking Resistor rated at 200 Ohms x 1500 Watts (1kW) continuous. Application: When connected to a suitable Inverter drive this will add braking to the drive system, by absorbing energy returning from the load.
Tolerance: ±5%. Dimensions: 430mm x 80mm x 136mm high including mesh cover (excluding terminal cover). Enclosure Rating: IP20 when mounted (Open to rear). Weight: 1.96kg.
Overload: Maximum 10 times Overload for 5 seconds every 90 seconds. Maximum Overload: Limited by the brake chopper Voltage to 722W for 230V Drives, or 2.8kW for 400V drives. Time to Max Temperature at full load: 30 minutes.
Nominal Voltage: 1000V AC/DC. Peak Voltage: 3000V. Klixon over-temperature protection included.
Part Number: RE/60x370SI/PR/TP/KL1500W200R5%
Download the technical details from the link below.
IRV 60 200R FL500 J 1.5KV
Order code: 24503
25+ in stock
IRV 100 200R
Order code: 19137
9 in stock
10+ normally 9 weeks
IRV 200 200R FL500 J 1.5KV
Order code: 24535
IRV 300 200R FL500 J 1.5KV
Order code: 24543
10+ in stock
IRV 500 200R FL500 J 1.5KV
Order code: 24549
4 in stock
5+ normally 7 weeks
RE/ 60x370 SI/PR/TP/KL 1000W 200R 5%
Order code: 24785
Delivery 4 weeks
SI/PR/BP/KL 2x60x370 3000W 200R
Order code: 23846
Delivery 3 weeks
